SYLGARD 170
Two-part, 1:1 mix, black, general purpose encapsulant with good flowability, long working time and flame resistance

DOW

SYLGARD™ 170 Silicone Elastomer is suitable for use as an encapsulant or
potting material.

Potential applications:

  • Power supplies
  • Connectors
  • Sensors
  • Industrial controls
  • Transformers
  • Amplifiers
  • High voltage resistor packs
  • Relays

Features & Benefits:

  • Low viscosity
  • Long working time
  • Room temp or heat accelerated cure
  • Moderate thermal conductivity
  • UL 94 V-0 and MIL1 Spec tested to MIL-PRF-23586F (specifically listed material numbers only)
  • Enhanced flow and fill in narrow spaces and around complex geometries
  • Rapid, versatile cure processing controlled by temperature
  • Provides stress relief in applications where hard, rigid encapsulants can cause damage during thermal cycling
  • Can be considered for uses requiring added flame resistance and MIL Spec applications
  • Approved for railways standard EN45545-2: R22/R23/R24/R25/R26 – HL3
Clear
SKU: 1696157 Category: Components: Manufacturer:

Download full specs
